Introduction to PSpice manual using Orcad release 9.2 for introductory circuits for electrical and computer engineeringUpplaga 1

Readers benefit because the book is based on these three themes: (1) it builds an understanding of concepts based on information the reader has previously learned; (2) it helps stress the relationship between conceptual understanding and problem-solving approaches; (3) the authors provide numerous examples and problems that use realistic values and situations to give users a strong foundation of engineering practice. The book also includes a PSpice Supplement which contains problems to teach readers how to construct PSpice source files; and this PSpice Version 9.2 can be used to solve many of the exercises and problems found in the book. Topical emphasis is on the basic techniques of circuit analysis -- Illustrated via a Digital-to-Analog Resistive Ladder (Chapter 2); the Flash Converter (Chapter 4); Dual Slope Analog-to-Digital Converter (Chapter 5); Effect of parasite inductance on the step response of a series RLC circuit (Chapter 6); a Two-Stage RC Ladder Network (Chapter 8); and a Switching Surge Voltage (Chapter 9).
