Encyclopedia of Electronic Circuits, Volume 7

This work contains an extensive library of 1,000 circuits from the bestselling, seven-volume "Encyclopedia of Electronic Circuits". 'A virtual treasurehouse...an invaluable reference tool for every hobbyist, technician, student, and design professional' - "Electronics For You". '...a ready source to which to turn for just about any type of circuit you can imagine...' - "Modern Electronics"This new edition contains another thousand circuit designs. Designed for quick reference and on-the-job use, the "Encyclopedia of Electronic Circuits, Volume 7", puts over 1000 state-of-the-art electronic and integrated circuit designs at your fingertips. Organized alphabetically by circuit type, this all-new collection includes the latest designs from industry giants such as Advanced Micro Devices, Motorola, Teledyne, General Electric, and others.For each circuit, you'll find a brief explanation of its operation and other information regarding adjustments or alignment. An invaluable reference tool, this book also includes a cumulative index that covers all the circuits here and in each of the previous 6 volumes.Inside you'll find diagrams and schematics for circuits used in: Power supplies; Computers; Amplifiers; Sine wave oscillators; Flow detectors; Filters; Frequency meters; Infrared devices; Games; Phase detectors; Optically coupled devices; Generators; Microwave receivers; Signal injectors; Time delay apparatuses; Laser tools; Probes; and many other applications!
